The Small Magellanic Cloud (SMC) is a dwarf galaxy. It has a diameter of about 7,000 light-years and contains several hundred million stars. It has a total mass of approximately 7 billion times the mass of our Sun. Some speculate that the SMC was once a barred spiral galaxy that was disrupted by the Milky Way to become somewhat irregular. It contains a central bar structure. At a distance of about 200,000 light-years, it is one of the Milky Way's nearest neighbors. It is also one of the most distant objects that can be seen with the naked eye. With a mean declination of approximately -73 degrees, it can only be viewed from the Southern Hemisphere and the lower latitudes of the Northern Hemisphere. It is located in the constellation of Tucanaand appears as a hazy, light patch in the night sky about 3 degrees across. It looks like a detached piece of the Milky Way. Since it has a very low surface brightness, it is best viewed from a dark site away from city lights. It forms a pair with the Large Magellanic Cloud (LMC), which lies a further 20 degrees to the east. The Small Magellanic Cloud is a member of the Local Group.

Observation history

In the southern hemisphere, the Magellanic clouds have long been included in the lore of native inhabitants, including south sea islanders and indigenous Australians. Persian astronomer Al Sufi labelled the larger of the two clouds as Al Bakr, the White Ox. European sailors may have first noticed the clouds during the Middle Ages when they were used for navigation. Portuguese and Dutch sailors called them the Cape Clouds, a name that was retained for several centuries. During the circumnavigation of the Earth by Ferdinand Magellan in 1519–22, they were described by Antonio Pigafetta as dim clusters of stars.

In Johann Bayer's celestial atlas Uranometria, published in 1603, he named the smaller cloud, Nubecula Minor. In Latin, Nubecula means a little cloud. Between 1834 and 1838, John Herschel made observations of the southern skies with his 14-inch (36 cm) reflector from the Royal Observatory at the Cape of Good Hope. While observing the Nubecula Minor, he described it as a cloudy mass of light with an oval shape and a bright center. Within the area of this cloud he catalogued a concentration of 37 nebulae and clusters. In 1891, Harvard College Observatory opened an observing station at Arequipa, Peru.

From 1893 and 1906, under the direction of Solon Bailey, the 24-inch (610 mm) telescope at this site was used to survey photographically both the Large and Small Magellanic Clouds. Henrietta Swan Leavitt, an astronomer at the Harvard College Observatory, used the plates from Arequipa to study the variations in relative luminosity of stars in the SMC. In 1908, the results of her study were published, which showed that a type of variable star called a "cluster variable", later called a Cepheid variable after the prototype star Delta Cephei, showed a definite relationship between the variability period and the star's luminosity.

This important period-luminosity relation allowed the distance to any other cepheid variable to be estimated in terms of the distance to the SMC. Hence, once the distance to the SMC was known with greater accuracy, Cepheid variables could be used as a standard candle for measuring the distances to other galaxies. Using this period-luminosity relation, in 1913 the distance to the SMC was first estimated by Ejnar Hertzsprung. First he measured thirteen nearby cepheid variables to find the absolute magnitude of a variable with a period of one day. By comparing this to the periodicity of the variables as measured by Leavitt, he was able to estimate a distance of 10,000 parsecs (30,000 light years) between the Sun and the SMC.This later proved to be a gross underestimate of the true distance, but it did demonstrate the potential usefulness of this technique.

X-ray sources

No X-rays above background were observed from the Magellanic Clouds during the September 20, 1966, Nike Tomahawk flight. Balloon observation from Mildura, Australia, on October 24, 1967, of the SMC set an upper limit of X-ray detection.

An X-ray astronomy instrument was carried aboard a Thor missile launched from Johnston Atoll on September 24, 1970, at 12:54 UTC for altitudes above 300 km, to search for the Small Magellanic Cloud. The SMC was detected with an X-ray luminosity (Lx) of 5 x 1038 ergs/s in the range 1.5-12 keV, and 2.5 x 1039 ergs/s in the range 5-50 keV for an apparently extended source. The fourth Uhuru catalog lists an early X-ray source within the constellation Tucana: 4U 0115-73 (3U 0115-73, 2A 0116-737, SMC X-1). Uhuru observed the SMC on January 1, 12, 13, 16, and 17, 1971, and detected one source located at 01149-7342, which was then designated SMC X-1. Some X-ray counts were also received on January 14, 15, 18, and 19, 1971. The third Ariel 5 catalog (3A) also contains this early X-ray source within Tucana: 3A 0116-736 (2A 0116-737, SMC X-1).The SMC X-1, a HMXRB, is at J2000 right ascension (RA) 01h 15m 14s declination (Dec) 73°42′22″. Two additional sources detected and listed in 3A include SMC X-2 at 3A 0042-738 and SMC X-3 at 3A 0049-726.
