The elements of an orbit are the parameters needed to specify that orbit uniquely, given a model of two point masses obeying the Newtonian laws of motion and the inverse-square law of gravitational attraction. Because there are multiple ways of parameterising a motion, depending on which set of variables you choose to measure, there are several different ways of defining sets of orbital elements, sets each of which will specify the same orbit.
This problem contains three degrees of freedom (the three Cartesian coordinates of the orbiting body). Therefore, each particular Keplerian ( = unperturbed) orbit is fully defined by six quantities - the initial values of the Cartesian components of the body's position and velocity. For this reason, all sets of orbital elements contain exactly six parameters. For a mathematically accurate explanation of this fact see the Discussion and references therein. (See also: orbital state vectors).
- Inclination ($ i\,\! $)
- Longitude of the ascending node ($ \Omega\,\! $)
- Argument of periapsis ($ \omega\,\! $)
- Eccentricity ($ e\,\! $)
- Semimajor axis ($ a\,\! $)
- Mean anomaly at epoch ($ M_o\,\! $)
Keplerian elements can be obtained from orbital state vectors using VEC2TLE software or by some direct computations. We see that the first three orbital elements are simply the Eulerian angles defining the orientation of the orbit relative to some fiducial coordinate system. The Keplerian elements parameterise a conic orbit emerging in an unperturbed two-body problem — an ellipse, a parabola, or a hyperbola. In a more realistic setting, a perturbed trajectory is represented as a sequence of such instantaneous conics that share one of their foci. In case the orbital elements are postulated to parameterise a sequence of conics that are always tangent to the trajectory, these orbital elements are called osculating.
Instead of the mean anomaly at epoch, $ M_o\,\! $, the mean anomaly $ M\,\! $, mean longitude, true anomaly or, rarely, the eccentric anomaly may also be used. Sometimes the epoch itself is used as the sixth orbital element. Other orbital parameters, such as the period, can then be calculated from the Keplerian elements. In some cases, the period is used as an orbital element instead of semi-major axis.
Visualizing an Orbit
In Fig. 1, the orbital plane (yellow) intersects a reference plane called the plane of ecliptic (grey). The intersection is called the line of nodes, as it connects the center of mass with the ascending and descending nodes. This plane, together with the Vernal Point, (♈) establishes a reference frame. The elements can be seen as defining the orbit in this frame by degrees:
- The semi-major axis (violet line in Fig. 1) fixes the size of the orbit. It connects the geometric center of the orbital ellipse with the periapsis, passing through the focal point where the center of mass resides. . As noted above, the orbital period also establishes the size of the orbit.
- The eccentricity fixes its shape.
- The longitude of the ascending node (green angle $ \Omega\,\! $ in Fig. 1) orients the ascending node with respect to the vernal point. Imagine the angle being formed by pivoting the orbital plane through an axis of rotation perpendicular to the plane of the ecliptic and passing through the center of mass.
- The inclination (green angle $ i\,\! $ in Fig. 1) orients the orbital plane with respect to the plane of the ecliptic. Imagine the angle being formed by pivoting the orbital plane through an axis of rotation coinciding with the line of nodes.
- The argument of periapsis (perhelion) (violet angle $ \omega\,\! $ in Fig. 1) orients the semimajor axis with respect to the ascending node. Imagine the angle being formed by pivoting the orbital plane through an axis of rotation perpendicular to itself and passing through the center of mass.
- The true anomaly (red angle $ T\,\! $ in Fig. 1) orients the celestial body in space. Imagine this positioning angle being formed by pivoting the body's position vector through an axis of rotation perpendicular to the orbital plane and passing through the center of mass.
Variance Among Keplerian Elements and Trajectories of Orbiting Bodies
Because the simple Newtonian model of orbital motion of idealised points in free space is not exact, the orbital elements of real objects tend to change over time. Evolution of the orbital elements takes place due to the gravitational pull of bodies other than the primary, due to the nonsphericity of the primary, due to the atmospheric drag, relativistic effects, radiation pressure, electromagnetic forces, and so on. This evolution is described by the so-called planetary equations, which come in the form of Lagrange, or in the form of Gauss, or in the form of Delaunay, or in the form of Poincaré, or in the form of Hill. (The latter is a very exotic option, emerging in the case when the true anomaly enters the set of six orbital elements. Hill considered this kind of orbit parameterisation back in 1913.)
For more information, see the Discussion.
Two line elements
Keplerian elements parameters can be encoded as text in a number of formats. The most common of them is the NASA/NORAD "two-line elements"(TLE) format , originally designed for use with 80-column punched cards, but still in use because it is the most common format, and works as well as any other.
Depending on the application and object orbit, the data derived from TLEs older than 30 days can become unreliable. Orbital positions can be calculated from TLEs through the SGP/SGP4/SDP4/SGP8/SDP8 algorithms.
Line 1 Column Characters Description ----- ---------- ----------- 1 1 Line No. Identification 3 5 Catalog No. 8 1 Security Classification 10 8 International Identification 19 14 YRDOY.FODddddd 34 1 Sign of first time derivative 35 9 1st Time Derivative 45 1 Sign of 2nd Time Derivative 46 5 2nd Time Derivative 51 1 Sign of 2nd Time Derivative Exponent 52 1 Exponent of 2nd Time Derivative 54 1 Sign of Bstar/Drag Term 55 5 Bstar/Drag Term 60 1 Sign of Exponent of Bstar/Drag Term 61 1 Exponent of Bstar/Drag Term 63 1 Ephemeris Type 65 4 Element Number 69 1 Check Sum, Modulo 10 Line 2 Column Characters Description ----- ---------- ----------- 1 1 Line No. Identification 3 5 Catalog No. 9 8 Inclination 18 8 Right Ascension of Ascending Node 27 7 Eccentricity with assumed leading decimal 35 8 Argument of the Perigee 44 8 Mean Anomaly 53 11 Revolutions per Day (Mean Motion) 64 5 Revolution Number at Epoch 69 1 Check Sum Modulo 10
- Explanatory Supplement to the Astronomical Almanac. 1992. K. P. Seidelmann, Ed., University Science Books, Mill Valley, California.
- Keplerian Elements tutorial
- another tutorial
- Spacetrack Report No. 3, a really serious treatment of orbital elements from NORAD (in pdf format)
- Celestrak Two-Line Elements FAQ
- The JPL HORIZONS online ephemeris. Also furnishes orbital elements for a large number of solar system objects.
- Introduction to the JPL ephemerides
- State vectors: VEC2TLE Access to VEC2TLE software
